| serial number | performance parameters | parameter |
| 1 | Input voltage | AC110V-240V |
| 2 | input frequency | 60Hz |
| 3 | Maximum load current | 16A |
| 4 | USB output | DC5V 2.1A(MAX) |
| 5 | communication standard |
ZIGBEE 3.0 / wifi 2.4GHz |
| 6 |
PER<8%.RX Sensitivity 802.11b CCK |
-91dBm |
| 7 |
PER10%.RX sensitivity 802.11g CCK |
-75dBm |
| 8 |
PER10%.RX sensitivity 802.11n CCK |
-72dBm |
| 9 | Security Mechanism | WAP/WAP2 |
| 10 | encryption type | WEP/TKIP/AES |
| 11 | Working power consumption | <1.3W |
| 12 | Standby power consumption | <0.7W |
| 13 | indicator light | Blue light (off) red light (on) green light (distribution network) |
| 14 | shell material | PC+ABS fire rating VO |
| 15 | Product Size | 122*52*65MM |
| 16 | product weight | 170g |
| 17 | Product packaging size | 132*57*80MM |
| 18 | Product box size | 570*330*440M |
| 19 | Product FCL Weight | 18.5KG British Standard (100PCS per box) |
| 20 |
1 Mobile phone remote control When both the mobile phone and the socket are connected to the Internet, the on/off status of the smart plug rate can be remotely controlled in the network environment through the mobile phone APP 2 Manual switch Cycle the on/off state by clicking the switch button on the socket 3 Timing function The mobile APP has a timing control switch function (repeated timing can be set). 4 Power Statistics None 5 Online upgrade When a new version of the APP is updated, it can be upgraded online in the APP to add more functions 6 Smart sharing can be shared with family and friends 7 Smart configuration Support Smartconfig function of Android and iOS |
|
